Main features:
1. The machine is suitable for the forming and blanking of one or more layers of leather, plastic, canvas, nylon, paperboard and various synthetic materials.
2, easy operation, simple, low failure rate, and no traditional cutting machine noise, less trouble, easy maintenance.
3. Press the button with both hands before blanking. And no continuous abuse, high security.
4. Electronic shi circuit is adopted to control the lower limit position of stroke with high precision. The height of swing arm from the table is adjusted with handwheel, which is convenient for adjustment.
5, swing arm cutting head, good sight zui in operation, material selection zui is convenient.
6. The cutting head made of special material is durable and has a good cutting effect.
7. The column is lubricated automatically to ensure less wear of zui.
8. Double-sided sharp cutting knife can be used to save labor and costTechnical parameters:
Zui big punching force (Max xutting The force) 200 kn Swinging arm size The arm 's The size) 550 * 350 mm Worktable's Surface 's The size) 1000 * 500 mm stroke 5-75 - mm Motor power Power) 1.5 kw Net weight (net Weight) 1050 kg Machine's The size) 1000 * 1000 * 1500 mm Hydraulic oil Oil) 55 l
